A cartridge captures suspended particles such as dirt and sand before they reach the main treatment tank.
Stainless Steel Whole Home Filter
Target chlorine taste, odor and sediment throughout your home with Crystal Quest SMART filtration. For municipal water; no softener included.
Swipe or select a thumbnail. Tap an image to enlarge.
Supplier model: CQE-WH-01120Compare model specsTreatment details
Installation and applicable taxes are separate.
Download installation instructions Get your plumber briefFollow the water.
See what each stage does. Select a stage to take a closer look.
A blend of filtration media treats a range of water-quality concerns through adsorption and redox processes. Match specific reduction needs to the exact manufacturer configuration.
The final carbon cartridge polishes the water for taste and odor. Replace it as conditions require; it is not a disinfection stage.
Treatment overview, not a plumbing diagram. Shows the base equipment only; selected add-ons require additional stages. Performance depends on water chemistry, flow and maintenance.
Treatment details & performance information
Three main pieces treat water where it enters your home: a sediment cartridge, a SMART media tank and a carbon-block cartridge.
SMART filtration targets chlorine taste, odor and sediment. Check manufacturer performance information for specific contaminant concerns. Results depend on water conditions, flow and maintenance.
Confirm that performance information applies to your exact model and water conditions.
Compare model specifications.
Manufacturer specifications for the Standard and Large models. Confirm your home’s peak demand before choosing.
| Specification | Standard | Large |
|---|---|---|
| Crystal Quest model | CQE-WH-01120 | CQE-WH-01121 |
| Bathroom starting guide | 1–3 bathrooms | 2–4 bathrooms |
| Main tank media | 1.5+ cu. ft. SMART media | 2.0+ cu. ft. SMART media |
| Nominal SMART filtration capacity | 1,000,000 gallons | 1,500,000 gallons |
| Listed service flow | 9–11 gallons/minute | 10–13 gallons/minute |
| Treatment tank size (diameter × height) | 10 × 54 inches | 12 × 52 inches |
| Treatment tank finish | Stainless steel | Stainless steel |
| Automatic control | Timed backwash | Timed backwash |
| Pre- & postfilter cartridges | 20-inch sediment + carbon block | 20-inch sediment + carbon block |
Source: Crystal Quest model specifications ↗
Listed service flow is not a guarantee of pressure at every fixture. Your plumber checks peak demand, incoming pressure and pipe size.
SMART gallon ratings are nominal media capacities, not cartridge replacement intervals or guarantees of contaminant reduction.
Tank dimensions alone are not installation clearance. Allow extra space for the control head, cartridge housings, bypass plumbing and maintenance access.
Installation requirements
-
A protected indoor location
Allow room around the tanks, control heads and cartridge housings for service. Protect the system from sunlight, weather and freezing.
-
An outlet within reach
The automatic controls need power. The manual calls for a nearby 110-volt outlet and says not to use an extension cord.
-
A suitable drain
Backwashing and softener regeneration discharge water. Your plumber plans the drain connection and sets the cleaning schedule.
-
Safe incoming pressure
The manual calls for a regulator if water pressure, including spikes, could exceed 60 psi. Your plumber confirms the limits for the supplied equipment.
What’s included.
Your equipment package and the costs to plan for separately.
Included in your package
-
SMART filtration tank
Stainless steel tank with the filtration media and control head.
-
Sediment + carbon cartridges
A prefilter for sediment and a carbon postfilter, with housings.
-
Leak-detection shutoff valve
The CQE-PT-03064 valve is part of this Clearhouse package.
Budget for these separately
- Your plumber’s labor and installation quote
- Any extra plumbing parts or site work
- Applicable taxes
- Future replacement cartridges and filtration media
Get a complete installation quote before ordering.
Choose your size.
Bathroom counts are a starting point. If the ranges overlap, consider how many showers and appliances run at the same time.
A starting point for 1–3 bathrooms.
The 1.5 cu. ft. option for a smaller or moderate-demand home. Your plumber checks whether its flow matches your busiest times.
A starting point for 2–4 bathrooms.
The 2.0 cu. ft. option for greater water demand. Useful to consider when multiple fixtures run at once.
Your plumber confirms peak flow, pressure, hardness and space. Larger homes and shared plumbing need individual review.
Picture it in your home.
A clean, organized setup at your main water line. Your licensed plumber plans the connections and service access for your space.

Your system. Your plumber.
Share your equipment brief and manual with a licensed plumber. Confirm the fit and get a separate installation quote before you order.
Manuals & manufacturer documents
Share these with your plumber. Follow the instructions supplied with your exact equipment.
Maintenance & replacement
Keep the system. Refresh the parts that do the work. Here’s what to plan for.
Replace the two cartridges
Change the sediment prefilter and carbon postfilter. Replace sooner if flow drops or your water conditions require it.
Service the tank media
The filtering material inside the main tank lasts several years, then needs replacement. Your water quality and usage determine the service interval.
Automatic backwashing or regeneration does not eliminate cartridge changes or eventual media replacement.
Care for the stainless steel finish. Wipe off condensation and keep salt away from the steel surfaces. Crystal Quest notes that persistent moisture, high humidity and salt exposure can cause rust or pinholes. Ask your plumber to confirm a suitable location.
Schedules & manufacturer sources
The whole-house manual recommends 12–18 months for pre- and postfilters. The individual sediment listing estimates 18–24 months for CQE-RC-04015. Follow your system manual and installer’s advice; actual service life depends on water quality and usage.
Follow the shutoff, pressure-release and flushing instructions. Your plumber can handle the change if you prefer.
A filter and softener do different jobs.
Choose the treatment that matches your water and existing equipment.
Stainless Steel Whole Home Filter
Everyday filtration. A starting point for chlorine taste, odors and sediment.
Stainless Steel Whole Home Softener
Hardness reduction. For scale control, on its own or with your existing filter.
Stainless Steel Whole Home Filter + Softener
Both jobs together. SMART filtration plus a separate salt-based softener.
Free U.S. shipping on equipment. Plumber installation and applicable taxes are separate.
Before you order.
Is this the right system for my home?
Start here if your home uses municipal water and you want filtration without a new softener. Your plumber confirms the water quality and system size. Private wells need their own testing and treatment review.
Do I need a water softener?
Choose a softener if you also want to reduce hard-water scale. Test incoming hardness first. Filtration alone does not replace softening.
Is installation included in the price?
No. Hire and pay your own licensed plumber. Equipment ships free within the U.S.; installation, site-specific parts and taxes are separate.
What ongoing maintenance should I expect?
Replace sediment and carbon cartridges every 12–18 months, or sooner if needed. Tank media has a separate service schedule based on water quality and use.
Will it remove everything in my water report?
No. Check exact-model performance for your concerns. A utility report is not a test of your tap.
Does it work on chloramine as well as chlorine?
Crystal Quest identifies both chlorine and chloramine as treatment targets for its standard and catalytic carbon blend. If your utility uses chloramine, review the exact system’s performance information against your water conditions and required flow before ordering.
Will this filter soften hard water?
This package has no dedicated softener or brine tank. Its SMART blend includes ion-exchange media, but we do not size or sell it as a replacement for a water softener. If reducing hardness scale is a goal, choose the Filter + Softener package or pair it with a suitable existing softener.
What does the automatic control do?
The control head schedules backwashing or softener regeneration so the tank can clean or restore its media. Crystal Quest lists a timed valve as the base configuration and a metered valve as an upgrade. Our listed packages do not include that upgrade. Your installer sets the controls for your water and usage.
What warranty information should I review?
The manufacturer’s whole-house manual describes a one-year limited warranty for defects in materials and workmanship, with component-specific terms. Routine cartridge replacement is excluded unless the cartridge is defective on receipt. Review the full terms in the owner’s manual and confirm coverage for the supplied package before ordering. Open PDF
Where can I see the technical details?
Supplier model: CQE-WH-01120 · Standard
Compare sizes, flow and dimensions in the model specifications above. Compare model specs
Unsure which water system fits?
Tell us about your water and home. We’ll suggest a starting system and explain the fit.
